5V Cylindrical Lithium Battery Product Model: XL 5V 13200mAh
Technical parameters of 5V cylindrical lithium battery (specific design according to customer requirements-voltage/capacity/size/line)
Single battery model: 18650
·Single battery voltage: 5V
·Nominal voltage after the battery pack is assembled: 5V
·Single battery capacity: 2.2Ah
·Battery combination mode: 1 string 6 parallels
·Battery voltage range after combination: 2.5~4.2V
·Battery capacity after combination: 13.2Ah
·Battery pack power: 48.84Wh
·Battery pack size: 18.5*115*67mm
·Maximum discharge current: <13.2A
·Instantaneous discharge current: 26.4~39.6A
·Maximum charging current: 0.2~0.5C
·Charging and discharging times: >500 times
·Main chip: (Seiko, TI)
5V cylindrical lithium battery
· Conform to relevant national or international battery standards
· All battery products are tested before leaving the factory
